Sectional Door Motor & Controller
| Type |
NY-SDO-50 |
NY-SDO-50S-1 |
NY-SDO-75S-1 |
| Input Voltage |
220×(1±10%)V 50Hz |
380×(1±10%)V 50Hz |
380×(1±10%)V 50Hz |
| Motor Speed |
1400rpm |
1400rpm |
1400rpm |
| Output Rotational Speed |
32rpm |
32rpm |
24rpm |
| Output Torque |
30N.m |
50N.m |
75N.m |
| Motor Power |
300W |
400W |
400W |
| Limit the maximum number of laps |
The output shaft may turn 28 laps |
The output shaft may turn 28 laps |
The output shaft may turn 28 laps |
| Aperture of Output Shaft |
Ø25.4mm |
Ø25.4mm |
Ø25.4mm |
| Keyway Size |
6mm |
6mm |
6mm |
| Thermal Protection Temperature |
120℃ |
120℃ |
120℃ |
| Working System |
S2:20% S3:10min |
S2:25% S3:15min |
S2:25% S3:15min |
| Operating Ambient Temperature |
-20℃～+45℃ |
-20℃～+45℃ |
-20℃～+45℃ |
| Overall Dimension |
100﹡233﹡360 |
100﹡233﹡360 |
100
﹡233﹡360
|
| Main Machine Mass |
12kg |
12kg |
12kg |
● The unique built-in braking system can furthest reduce the inertial stroke of industrial doors and make stop positions of doors accurate;
● The safe and reliable disengaging wrench facilitates the installation of users, the adjustment and maintenance of balancing springs and use during power outage;
● Having a thermal protection function, and high safety and reliability;
● Above IP54 of safety protection class;
● The low-temperature lubricating oil ensures that the machine runs stably, has low noise and a long service life, and is suitable for working in cold areas;
● Mechanical and electrical integration; the devices such as a remote control, a safety air bag and a photoelectric switch are optional;
● Convenient and accurate stroke adjustment;
● The performance parameters of the product are completely in accordance with the industrial standard of Industrial Sliding Door Openers of MOHURD.
